Dell R660
1U rack · 10 × 2.5" bays · 2 full-height PCIe slots · 32 DIMM slots · 2 sockets · in stock
Configure this rack server Browse all servers
Dell R660 configurations available
| Configuration |
|---|
| Dell PowerEdge R660 1U 10S LGA4677 |
| Dell PowerEdge R660 1U 8S LGA4677 Nvme |
Dell R660 specifications
Dell PowerEdge R660
Processor
- Up to two 4th or 5th Generation Intel Xeon Scalable (LGA4677)
- Up to 56 cores per CPU (4th gen); sources list up to 64 with 5th gen
Memory
- 32 DDR5 DIMM slots, RDIMM only, up to 8 TB
- 4800 MT/s (4th gen), up to 5600 MT/s with 5th gen
Drive bays
- Front: up to 10 × 2.5" SAS/SATA/NVMe (153.6 TB) or up to 8 × 2.5" (122.88 TB)
- Rear: up to 2 × 2.5" SAS/SATA/NVMe
- E3.S bays on some configurations
Storage controllers
- Internal RAID: PERC H965i, H755, H755N, H355, HBA355i
- Boot: BOSS-N1 with 2 × M.2 NVMe in hardware RAID, or USB
- External: HBA355e; software RAID S160
Expansion slots
- Up to three slots: Slot 1 and 2 x16 Gen5 full height, Slot 3 x8/x16 Gen5 or x16 Gen4 low profile
Network
- Optional 1 × OCP 3.0 card (NDC), optional 2 × 1GbE LOM, either or both
Power supply
- Hot-swap redundant: 1800 W Titanium, 1400 W Platinum, 1100 W Titanium, 1100 W LVDC (−48 to −60 VDC), 800 W Platinum, 700 W Titanium
Management
- iDRAC9 with iDRAC Direct, Redfish RESTful API, iDRAC Service Module
Dimensions
- 1U rack chassis; 42.8 mm high, 482 mm wide
- 822.88 mm deep with bezel, 809.04 mm without
<!-- source: xByte R660 page; core count and memory speed differ between its sections, checked 2026-10-15 -->
Buying a Dell R660 from IT Server Exchange
Every unit is tested before it ships and its condition is stated up front. Build one to your own specification in the configurator — processors, memory, drives, controllers, network cards and rails are matched to this chassis, so the parts offered are the ones that fit — then send the configuration over and we'll quote it.
