Dell R750
2U rack · 12 × 3.5" bays · 4 full-height + 2 low-profile PCIe slots · in stock
Configure this rack server Browse all servers
Dell R750 configurations available
| Configuration |
|---|
| Dell PowerEdge R750 2U 24S LGA3647 |
| Dell PowerEdge R750 2U 16S LGA4189 |
| Dell PowerEdge R750 2U 24S LGA4189 |
| Dell PowerEdge R750 2U 12L LGA4189 |
| Dell Poweredge R750 2U 8S LGA3647 |
Dell R750 specifications
Dell PowerEdge R750
Processor
- Up to two 3rd Generation Intel Xeon Scalable (LGA4189), up to 40 cores each
Memory
- 32 DDR4 DIMM slots, up to 3200 MT/s
- Up to 16 Intel Persistent Memory 200 series slots
Drive bays
- Front: up to 12 × 3.5" SAS/SATA, up to 24 × 2.5" SAS/SATA/NVMe, up to 16 × 2.5", or up to 8 × 2.5" NVMe
- Rear: up to 2 or 4 × 2.5" SAS/SATA/NVMe
Storage controllers
- Internal: PERC H745, H755, H755N, H345, HBA355i, S150
- Boot: BOSS-S1 or BOSS-S2, hardware RAID on 2 × M.2 240 GB or 480 GB
- External: PERC H840, HBA355e
Expansion slots
- Up to 8 × PCIe Gen4 slots, up to 6 of them x16
- SNAP I/O modules supported
Network
- 2 × 1GbE LOM onboard
- 1 × OCP 3.0 network daughter card (x8 lanes)
Power supply
- Hot-swap redundant: 800 W Platinum, 1100 W Titanium, 1400 W Platinum, 2400 W Platinum (AC/240 HVDC)
Management
- iDRAC9 with iDRAC Service Module, iDRAC Direct, Quick Sync 2
Dimensions
- 2U rack chassis; 86.8 mm high, 482 mm wide
- 772.14 mm deep with bezel, 758.3 mm without
<!-- source: xByte R750 product page; its Details and Tech Specs sections list different PSU ranges, checked 2026-10-15 -->
Buying a Dell R750 from IT Server Exchange
Every unit is tested before it ships and its condition is stated up front. Build one to your own specification in the configurator — processors, memory, drives, controllers, network cards and rails are matched to this chassis, so the parts offered are the ones that fit — then send the configuration over and we'll quote it.
